| Λοιπά χαρακτηριστικά : |
Τύπος: ATX Form Factor; 30.5cm x 24.4cm.Επεξεργαστές: Support for 9th and 8th Generation Intel Core i9 processors/ Intel Core i7 processors/ Intel Core i5 processors/ Intel Core i3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1151 package, L3 cache varies with CPU.Chipset: Intel Z390 Express Chipset.Μνήμες: 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory, Dual channel memory architecture, Support for DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules, Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for Extreme Memory Profile (XMP) memory modules.Υποστήριξη δίσκων: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2M), 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A), 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x4/x2 SSD support) (M2P), 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10.Θύρες επέκτασης: 1 x PCI Express x16 slot, running at x16 (PCIEX16), 1 x PCI Express x16 slot, running at x8 (PCIEX8), 1 x PCI Express x16 slot, running at x4 (PCIEX4), 2 x PCI Express x1 slots, 1 x M.2 Socket 1 connector for an Intel CNVi wireless module (CNVI).Εσωτερικές συνδέσεις: 1 x 24-pin ATX main power connector, 2 x 8-pin ATX 12V power connectors, 1 x OC PEG power connector, 1 x CPU fan header, 1 x water cooling CPU fan header, 4 x system fan headers, 2 x system fan/water cooling pump headers, 2 x addressable LED strip headers, 2 x addressable LED strip power select jumpers, 2 x RGB LED strip headers, 6 x SATA 6Gb/s connectors, 3 x M.2 Socket 3 connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C port, with USB 3.1 Gen 2 support, 1 x USB 3.1 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only), 1 x GC-OC Touch add-in card connector, 1 x Clear CMOS jumper, 2 x temperature sensor headers, 1 x power button, 1 x reset button, 1 x Clear CMOS button, 1 x OC button, 2 x BIOS switches.Εξωτερικές συνδέσεις: 2 x SMA antenna connectors (2T2R), 2 x Thunderbolt 3 connectors (USB Type-C ports, with USB 3.1 Gen 2 support), 4 x USB 3.1 Gen 2 Type-A ports (red), 2 x USB 3.1 Gen 1 ports, 2 x USB 2.0/1.1 ports, 1 x HDMI port, 2 x RJ-45 ports, 1 x optical S/PDIF Out connector, 5 x audio jacks.Γραφικά: Integrated Graphics Processor+Intel Thunderbolt 3 Controller: 2 x Intel Thunderbolt 3 connectors (USB Type-C ports), supporting DisplayPort and Thunderbolt video outputs and a maximum resolution of 4096x2304@60 Hz / Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz / Maximum shared memory of 1 GB.Ενσωματωμένη κάρτα ήχου: Realtek ALC1220-VB codec, ESS SABRE 9118 DAC, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out.Ενσωματωμένη κάρτα δικτύου: 1 x Aquantia GbE LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1000 Mbit/100 Mbit) (LAN1), Intel GbE LAN chip (10/100/1000 Mbit).Ασύρματη επικοινωνία: Intel CNVi interface 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band, BLUETOOTH 5, Support for 11ac 160 MHz wireless standard and up to 1.73 Gbps data rate.Συμβατό λειτουργικό σύστημα: Support for Windows 10 64-bit.Εγγύηση: 3 χρόνια. |
