| Λοιπά χαρακτηριστικά : |
Επεξεργαστές: Υποστηρίζει 8ης γενιάς Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors in the LGA1151 package, L3 cache varies with CPU.Chipset: Intel Z370 Express.Μνήμες: 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory, Dual channel memory architecture, Support for DDR4 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules, Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for Extreme Memory Profile (XMP) memory modules.Ενσωματωμένα Γραφικά: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz(The DVI-D port does not support D-Sub connection by adapter), 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz(Support for HDMI 1.4 version and HDCP 2.2) Support for up to 3 displays at the same time, Maximum shared memory of 1 GB.Ενσωματωμένη Κάρτα Ήχου: Realtek ALC1220 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out.Ενσωματωμένη Κάρτα Δικτύου: Intel GbE LAN chip (10/100/1000 Mbit).Θύρες Επέκτασης: 1 x PCI Express x16 slot, running at x16 (PCIEX16)(For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot), 1 x PCI Express x16 slot, running at x4 (PCIEX4)( he PCIEX4 slot shares bandwidth with the M2Q_32G connector. The PCIEX4 slot will become unavailable when an SSD is installed in the M2Q_32G connector), 4 x PCI Express x1 slots(All of the PCI Express slots conform to PCI Express 3.0 standard.), 1 x PCI slot.Αποθήκευση: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2Α_32G), 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x4/x2 SSD support) (M2Q_32G), 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10(Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors), Intel Optane Memory Ready.Τεχνολογία πολλαπλών Γραφικών: Support for AMD Quad-GPU CrossFireΧ and 2-Way AMD CrossFire technologies.USB: Chipset+ASMedia USB 3.1 Gen 2 Controller: 1 x USB Type-C port on the back panel, with USB 3.1 Gen 2 support, 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel, Chipset: 1 x USB Type-C port with USB 3.1 Gen 1 support, available through the internal USB header, 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header), 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers).Εσωτερικές Συνδέσεις: 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 2 x M.2 Socket 3 connectors, 6 x SATA 6Gb/s connectors, 1 x CPU fan header, 3 x system fan headers, 1 x RGB LED strip header, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C header, with USB 3.1 Gen 1 support, 1 x USB 3.1 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x S/PDIF Out header, 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only), 1 x serial port header, 1 x parallel port header, 1 x Clear CMOS jumper.Εξωτερικές Συνδέσεις: 1 x PS/2 keyboard/mouse port, 1 x D-Sub port, 1 x DVI-D port, 1 x HDMI port, 1 x USB Type-C port, with USB 3.1 Gen 2 support, 1 x USB 3.1 Gen 2 Type-A port (red), 4 x USB 3.1 Gen 1 ports, 2 x USB 2.0/1.1 ports, 1 x RJ-45 port, 6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In).I/O Controller: iTE I/O Controller Chip.Παρακολούθηση H/W: Voltage detection, Temperature detection, Fan speed detection, Overheating warning, Fan fail warning, Fan speed control (Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install).BIOS: 2 x 128 Mbit flash, Use of licensed AMI UEFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0.Ειδικά Χαρακτηριστικά: Support for APP Center(Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications): 3D OSD, @BIOS, AutoGreen, BIOS Setup, Color Temperature, Cloud Station, EasyTune, Easy RAID, Fast Boot, Game Boost, ON/OFF Charge, Platform Power Management, RGB Fusion, Smart Backup, Smart Keyboard, Smart TimeLock, System Information Viewer, USB Blocker, V-Tuner, Support for Q-Flash, Support for Xpress Install.Πακέτο λογισμικού: Norton Internet Security (OEM version), cFosSpeed.Λειτουργικό Σύστημα: Υποστηρίζει Windows 10 64-bit.Μέγεθος: ATX Form Factor (30.5cm x 24.4cm).Εγγύηση: 3 χρόνια. |
