| Λοιπά χαρακτηριστικά : |
Τοποθέτηση: Micro-ATX.Υποδοχή: 1151Υποστηριζόμενοι επεξεργαστές: υποστηρίζει 7th and 6th Generation Intel CoreTM i7/i5/i3/Pentium/Celeron επεξεργαστέςΥποστήριξη κάρτας γραφικών: 3 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3/PCIE4: single at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE3); triple at x8 (PCIE1) / x8 (PCIE3) / x4 (PCIE4)), 1 x PCI Express 3.0 x1 Slot (Flexible PCIe).Μνήμες: Dual Channel DDR4 Memory TechnologyΥποστήριξη Δίσκων: 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 and Intel Smart Response Technology), NCQ, AHCI and Hot Plug. 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)** - 1 x Ultra M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)** *If M2_1 is occupied by a SATA-type M.2 device, SATA3_5 will be disabled. If M2_2 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled. Υποστήριξη εγκατάστασης Intel Optane Memory στο Ultra M.2 slot.Θύρες επικοινωνίας (εξωτερικές): 1 x PS/2 Mouse/Keyboard Port, 1 x D-Sub Port, 1 x DVI-D Port, 1 x HDMI Port, 1 x Optical SPDIF Out Port, 1 x USB 3.1 Type-A Port (10 Gb/s) (ASMedia ASM2142) (Supports ESD Protection (ASRock Full Spike Protection)), 1 x USB 3.1 Type-C Port (10 Gb/s) (ASMedia ASM2142) (Supports ESD Protection (ASRock Full Spike Protection)), 4 x USB 3.0 Ports (Intel Z270) (Supports ESD Protection (ASRock Full Spike Protection)), 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone.Θύρες επικοινωνίας (εσωτερικές): 1 x COM Port Header, 1 x TPM Header, 1 x Chassis Intrusion Header, 1 x Power LED and Speaker Header, 1 x AURA RGB LED Header, 1 x CPU Fan Connector (4-pin)**, 1 x CPU Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control), 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control), 1 x Chassis Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control), 1 x 24 pin ATX Power Connector (Hi-Density Power Connector), 1 x 8 pin 12V Power Connector (Hi-Density Power Connector), 1 x Front Panel Audio Connector (15μ Gold Audio Connector), 1 x Thunderbolt AIC Connector (5-pin), 1 x Thunderbolt AIC Connector (10-pin), 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Intel Z270) (Supports ESD Protection (ASRock Full Spike Protection)), 2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (ASMedia ASM1074 hub) (Supports ESD Protection (ASRock Full Spike Protection)), 1 x Vertical Type A USB 3.0 (Intel Z270).On-board συσκευές:Ενσωματωμένη κάρτα δικτύου: Gigabit LAN 10/100/1000 Mb/s.Ενσωματωμένη κάρτα ήχου: 7.1 CH HD Audio with Content Protection.Εγγύηση: 3 έτη. |
